Customizing Your Phone
81
Importing a CSV Contact List File
Procedure:
1. Click Directory->Local Directory.
2. Click Browse to choose a contact list file (the file format must be *.csv) from your local
system.
3. (Optional.) Check the Show Title checkbox.
It will prevent importing the title of the contact information which is located in the first line
of the CSV file.
4. Click Import CSV to import the contact list.
5. (Optional.) Mark the On radio box in the Del Old Contacts field.
It will delete all existing contacts while importing the contact list.
6. Select the contact information you want to import into the local directory from the Index
field.
At least one item should be selected to be imported into the local directory.
7. Click Import.
Exporting an XML/CSV Contact List
Procedure:
1. Click Directory->Local Directory.
2. Click Export XML (or Export CSV).
3. Click Save to save the contact list to your local system.
