YL9110 Quaternary Pump
Pump Head Assembly
Pump head is real working part to deliver solvent by piston movement and check valve. It consists of
plunger, check valve, high pressure seal, low pressure seal and rinsing port. YL9110 quaternary pump
built in automatic rinsing port to clean the head assembly efficiently if uses buffer solution.
Auto Rinsing Pump
Auto rinsing pump delivers cleaning solvent from the rinsing solvent bottle to the inside of pump head.
YL9110 quaternary pump rinse the system every 3 minutes automatically.
Prime/purge valve
This valve is used for priming the pump. Fill the solvent inside of tubing from the solvent bottle if you use
the pump for the first time or the tubing lines are empty. Remove a plug on the prime/purge valve and
suck the solvent using syringe, or click “Prime Start” button on the software to operate the micro pump.
Prime micro pump
Using this pump, the pump circulates rinse solvent into the pump head.
Solenoid valve
It is mixing valve for low pressure gradient. YL9110 quaternary pump controls this valve for gradient
according to solvent ratio and pump speed.
Mixer
It is static mixer to improve mixing efficiency of solvent.
Pulse damper
YL9110 quaternary pump reduces pulse from the cam operation by the diaphragm damper. YL9110
quaternary pump provides constant and pulseless flow using compressibility compensation and pulse
damper, so the detector that affected by flow stability can be used with YL9110 pump.
Pressure transducer
It checks real time system pressure. The pump uses this pressure to protect system and to operate
compressibility compensation and even compensation. YL9110 quaternary pump uses continuous flow
path type pressure sensor.
In-line filter
It removes fine particles that are not filtered by solvent filter or made by worn of high pressure seal.
4
