<10. Explosion Protected Type Instrument>
82
IM 01E20A01-01EN
10.5 TIIS
CAUTION
The model AXFCmagneticowmeterand
AXFA14C remote converter with optional code
JF3,whichhaveobtainedcerticationaccordingto
technical criteria for explosion-protected construction
of electric machinery and equipment (Standards
NoticationNo.556fromtheJapaneseMinistryof
Labor) conforming to IEC standards, are designed for
hazardousareaswhereinammablegasesorvapors
may be present. (This allows installation in Division 1
and 2 areas)
Topreservethesafetyofameproofequipment
requires great care during mounting, wiring, and
piping. Safety requirements also place restrictions on
maintenance and repair activities. Users absolutely
mustread“INSTALLATIONANDOPERATING
PRECAUTIONS FOR TIIS FLAMEPROOF
EQUIPMENT”attheendofthismanual.
(1) Technical Data
(AXF Integral Flowmeter), (AXF Remote Flowtube)
• Certicate:
Wafer Type;
Lining / Process
Connection
code
Size: mm (inch)
Integral Flowmeter Remote Flowtube
PFA
Lining
Ceramics
Lining
PFA
Lining
Ceramics
Lining
-A** -A** -A** -A**
2.5 (0.1) TC18966 TC16645 TC18982 TC16669
5 (0.2) TC18966 TC16645 TC18982 TC16669
10 (0.4) TC18966 TC16645 TC18982 TC16669
15 (0.5) TC18966 TC16646 TC18982 TC16670
25 (1.0)
(Lay length code 1)
TC16631 TC16647 TC16655 TC16671
25 (1.0)
(Lay length code 2)
TC18967 — TC18983 —
32 (1.25) TC16632 — TC16656 —
40 (1.5) TC16633 TC16648 TC16657 TC16672
50 (2.0) TC16634 TC16649 TC16658 TC16673
65 (2.5) TC16635 — TC16659 —
80 (3.0) TC16636 TC18978 TC16660 TC18994
100 (4.0) TC16637 TC18979 TC16661 TC18995
125 (5.0) TC16638 — TC16662 —
150 (6.0) TC18968 TC18980 TC18984 TC18996
200 (8.0) TC18970 TC18981 TC18986 TC18997
250 (10) TC18972 — TC18988 —
300 (12) TC18974 — TC18990 —
350 (14) — — — —
400 (16) — — — —
Flange Type (PFA lining only);
Lining / Process
Connection
code
Size: mm (inch)
Integral Flowmeter Remote Flowtube
PFA
Lining
PFA
Lining
-B**, -D** -B**, -D**
2.5 (0.1) TC18966 TC18982
5 (0.2) TC18966 TC18982
10 (0.4) TC18966 TC18982
15 (0.5) TC18966 TC18982
25 (1.0) TC16631 TC16655
32 (1.25) TC16632 TC16656
40 (1.5) TC16633 TC16657
50 (2.0) TC16634 TC16658
65 (2.5) TC16635 TC16659
80 (3.0) TC16636 TC16660
100 (4.0) TC16637 TC16661
125 (5.0) TC16638 TC16662
150 (6.0) TC18969 TC18985
200 (8.0) TC18971 TC18987
250 (10) TC18973 TC18989
300 (12) TC18975 TC18991
350 (14) TC18976 TC18992
400 (16) TC18977 TC18993
(AXF Integral Flowmeter)
• Construction: Ex de[ia] IIC T4
: Converter; Explosion proof
Flowtube; Increased Safety and
Intrinsically Safety(ia)
Electrode; Intrinsically Safety(ia)
Um=250VAC 50/60Hz, 250VDC,
Uo=250V*, Io=3.37mA*, Po=0.211W
*Uo and Io are rms value.
• Gas Group and Temperature Class: IIC T4
• Ambient Temperature: –20 to 60°C (power supply
code 1)
: –20 to 50°C (power supply
code 2)
• Fluid Temperature: 120°C max
• Electrode Circuit: 250 V AC/DC
• Maximum power supply voltage: 250V AC/130V DC
• Grounding:JISClassC(groundingresistance10Ωor
less)orJISClassA(groundingresistance
10Ωorless)
WARNING
In case that ambient temperature exceeds 50°C,
use heat-resistant cables with maximum allowable
temperature of 70°C or above.
(AXF Remote Flowtube)
• Construction: Ex de[ia] IIC T4
: Terminal box; Explosion proof
Flowtube; Increased Safety and
Intrinsically Safety(ia)
Electrode; Intrinsically Safety(ia)
Um=250VAC 50/60Hz, 250VDC,
Uo=250V*, Io=3.37mA*, Po=0.211W
*Uo and Io are rms value.
