YOKOGAWA CA550 Getting Started Guide

IM CA500-02EN
29
Resistance/RTD Source*
Thermocouple Source
−
+
V
−
+
V
When using the TC-A mini plug terminal
When using the banana plug*
Thermocouple measurement
−
When using the TC-A mini plug terminal
When using the banana plug*
Ω
Resistance/RTD Measurement (4W)
Resistance/RTD Measurement (3W)
Resistance/RTD Measurement (2W)
+
−
+
Pulse Source
Pulse Measurement (4W)
Hz
−
+
−
+
−
*: Example of using a binding post
Attach according to the terminal color.
Before using the included binding post, remove the short plate attached to the binding
post.
2 Preparation before Use
