YOKOGAWA CA550 Getting Started Guide

IM CA500-02EN
43
5. Specifications
5.1 DC Voltage, DC Current, Resistance and Pulse
Source
DC Voltage Source
Range Resolution Source Range
Accuracy (1 year)
±(% of setting + offset)
Notes
CA500 CA550
100 mV 1 μV ±110.000 mV 0.015% + 10 μV 0.015% + 5 μV Maximum output
current: 10 mA
1-5V 0.1 mV 0.0000 to
6.0000 V
0.015% + 0.5 mV Maximum output
current: 10 mA
Value output function
supporting square
root computation is
available.
5 V 0.1 mV ±6.0000 V 0.015% + 0.5 mV Maximum output
current: 10 mA
30 V 1 mV ±33.000 V 0.015% + 5 mV Maximum output
current: 1 mA
Accuracy guaranteed under +23°C±5°C, 20 to 80%RH
Add a temperature coefficient of 0.005% of Range/°C for -10°C to +18°C and +28°C
to +50°C.
The source accuracy is defined for the following conditions.
• The specified cable is used to source the signal.
• The effect of the voltage drop in the cable is excluded.
• The effect of the aging of the instrument is excluded.
DC Current Source
Range Resolution Source Range
Accuracy (1 year)
±(% of setting + offset)
Notes
CA500 CA550
20 mA 1
μA ±24.000 mA 0.015% + 3 μA 0.010% + 2 μA Source voltage: 0 to
+20 V
4-20 mA 1
μA 0.000 to
24.000 mA
(4.000 mA steps)
0.015% + 3 μA 0.010% + 2 μA Source voltage: 0 to
+20 V
Value output function
supporting square
root computation is
available.
20 mA
SIMULATE
1
μA 0.000 to
+24.000 mA
0.015% + 3 μA 0.010% + 2 μA External power
supply +5 to +28 V
Accuracy guaranteed under +23°C±5°C, 20 to 80%RH
Add a temperature coefficient of 0.005% of Range/°C for -10°C to +18°C and +28°C
to +50°C.
