YOKOGAWA CA550 Getting Started Guide

IM CA500-02EN
61
Accuracy guaranteed under +23°C±5°C, 20 to 80%RH
Add a temperature coefficient of 0.05°C/°C for -10°C to +18°C and +28°C to
+50°C.
Accuracies through four-wire system measurement
For accuracies through three-wire system measurement, add 1.0°C for Cu10,
0.6°C for Pt50, Pt50G, and Cu50M, and 0.3°C for other RTDs. However, this
assumes that the resistances of all cables are the same.
Assume the accuracies through two-wire system measurement to be the same
as those through three-wire system measurement. However, cable resistance
are not taken into consideration.
Display resolution of source/measured values: 0.1°C
1 Complies also with JIS C 1604
CA550
RTD
Coef Source/measurement accuracy (1 year,
t: source/measurement temperature)
Allowable
Excitation
Current
Standard,
Citation
Temperature Range
CA550
±
[°C]
PT100
3851 -200.0°C ≤ t < +100.0°C 0.1 0.1 to 3 mA IEC60751
1
+100.0°C ≤ t ≤ +800.0°C 0.1+(t-100) x
0.033%
3850 -200.0°C ≤ t < +100.0°C 0.1 0.1 to 3 mA JIS C 1604
1989
(Pt100)
+100.0°C ≤ t ≤ +630.0°C 0.1+(t-100)x
0.033%
3916 -200.0°C ≤ t < +100.0°C 0.1 0.1 to 3 mA JIS C 1604
1989
(JPt100)
+100.0°C ≤ t ≤ +510.0°C 0.1+(t-100)x
0.033%
3926 -200.0°C ≤ t < +100.0°C 0.1 0.1 to 3 mA Minco
Application Aid
#18
+100.0°C ≤ t ≤ +630.0°C 0.1+(t-100)x
0.033%
PT200
3851 -200.0°C ≤ t < +100.0°C 0.1 0.05 to
3 mA
IEC60751
1
+100.0°C ≤ t ≤ +630.0°C 0.1+(t-100)x
0.033%
PT500
3851 -200.0°C ≤ t < +100.0°C 0.1 0.05 to
0.6 mA
IEC60751
1
+100.0°C ≤ t ≤ +630.0°C 0.1+(t-100)x
0.033%
PT1000
3851 -200.0°C ≤ t < +100.0°C 0.1 0.05 to
0.6 mA
IEC60751
1
+100.0°C ≤ t ≤ +630.0°C 0.1+(t-100)x
0.033%
Cu10
427 -100.0°C ≤ t ≤ +260.0°C 1.2 0.1 to 3 mA Minco
Application Aid
#18
Ni120
627 -80.0°C ≤ t ≤ +260.0°C 0.1 0.1 to 3 mA Minco
Application Aid
#18
PT50
3851 -200.0°C ≤ t < +100.0°C 0.2 0.1 to 3 mA IEC60751
1
+100.0°C ≤ t ≤ +630.0°C 0.2+(t-100)x
0.033%
5. Specifications
