YOKOGAWA DL2700 Series User Manual

5 - 4
SM 700820-01E
(1)’
A short may occur in an assembly other than the power supply unit.
To check in which voltage line a short has occurred, investigate each assembly to which
voltage is supplied, using a circuit tester.
‘Table 5.1 Correspondence of Assembly to Voltage’ shows the relationship between
assemblies and voltages supplied to them.
Table 5.1 Correspondence of Assembly to Voltage
Voltage series Assembly
AFC Board Assembly
TRG Board Assembly
ACQ Board Assembly
Memory Board Assembly
Logic I/F Board Assembly (Option)
960 CPU Board Assembly
68k CPU Board Assembly
Video Board Assembly
+5V Printer Board Assembly (Option)
Mother Board Assembly
KEY Board Assembly
LCD Board Assembly
SCSI Board Assembly
LCD Assembly
Printer Assembly (Option)
MO Disk Drive Assembly (Option)
FDD Assembly
AFC Board Assembly
TRG Board Assembly
-5V ACQ Board Assembly
Logic I/F Board Assembly
Mother Board Assembly
AT T Board Assembly
AFC Board Assembly
TRG Board Assembly
+12V ACQ Board Assembly
Logic I/F Board Assembly
Mother Board Assembly
Rear Assembly
AT T Board Assembly
AFC Board Assembly
-12V TRG Board Assembly
Logic I/F Board Assembly
Mother Board Assembly
Rear Assembly
Printer Board Assembly (Option)
+24V Mother Board Assembly
KEY Board Assembly
Printer Assembly (Option)
Fan
