YOKOGAWA DL350 Getting Started Guide

6-6
IM DL35 O -03EN
6.4 Time Axis
Item Specifications
Time axis accuracy ±0.001%
External clock input Clock input through the external clock input terminal
6.5 Display
Item Specifications
Display 8.4-inch color TFT LDC1 (resistive touch panel)
Display pixels: 800 (horizontal) × 600 (vertical)
Display format T-Y (maximum number of divisions: 16, zoom function available), X-Y, FFT, harmonic analysis
Defective pixels 10 ppm or less of the total number of pixels including RGB
6.6 Main Unit Standard Logic Input
Item Specifications
Input type Non-insulated (shared with the main unit GND), uses dedicated probes (auto detection)
Compatible probes 700986, 700987, 702911, 702912
Maximum sample rate 10 MS/s
Number of inputs 8 bits × 2
Chatter suppression Off, 5 ms, 10 ms, 20 ms, 50 ms, 100 ms
6.7 Saving Data
Saving Data
Item Specifications
Types of saved data Measured data, analysis results, settings, screen capture
Measured data format Binary (.WDF), MATLAB (.MAT), text (.CSV)
Maximum file size (MAT, CSV format): 2 GByte
Data storage media SD memory card, USB storage, network drive
Saving Screen Captures
Item Specifications
Screen capture data format PNG, JPEG, BMP, monochrome or color
Data storage media SD memory card, USB storage, network drive
