6-45
IM DL35
O
-03EN
Specifications
1
2
3
4
5
6
App
Index
6.15
16-CH Scanner Box Specifications
For the specifications other than the dimensions of the 16-CH Scanner Box, see the 16-CH
T
emperature/Voltage Input Module (720221) specifications.
External Dimensions
Unit: mm
Unless otherwise specified, tolerances are ±3% (however
, tolerances are ±0.3 mm when below 10
mm).
Attaching plate
DL350
ø3.5
6
164.5
3.5
70
177
148
74
35
21
5
184
186
