Logic Probe (702911 and 702912)
Item Specifications
Number of inputs 8
Input format Non-isolated (all the bits share the same ground with the DL350 and each other)
Maximum input voltage ±35 V
Response time 3 µs (typical value
1
)
Input impedance 10 kΩ or more
Threshold level Approx. 1.4 V
Input methods TTL level or contact input (switchable). During contact input: Pulled up to 5 V
1 Typical value represents a typical or average value. It is not strictly warranted.
Note
Before using logic probes (702911, 702912) or isolated logic probe 700987, flip the attenuation switch back
and forth several times. The switch’s electrical contacts can weaken if not used for long periods of time.
6.14 Logic Probe Specifications
