When the Record Length Is 25 M, 50 M, 100 M, 250 M, 500 Mkpoint
Time/div
Record length
25 M 50 M 100 M 250 M 500 M
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
1 µs – – – – – – – –
2 µs – – – – – – – –
5 µs – – – – – – – –
10 µs 1 M 100 1 M 100 1 M 100 – –
20 µs 1 M 200 1 M 200 1 M 200 – –
50 µs 1 M 500 1 M 500 1 M 500 – –
100 µs 1 M 1.0 k 1 M 1.0 k 1 M 1.0 k – –
200 µs 1 M 2.0 k 1 M 2.0 k 1 M 2.0 k – –
500 µs 1 M 5.0 k 1 M 5.0 k 1 M 5.0 k – –
1 ms 1 M 10.0 k 1 M 10.0 k 1 M 10.0 k – –
2 ms 1 M 20.0 k 1 M 20.0 k 1 M 20.0 k – –
5 ms 1 M 50.0 k 1 M 50.0 k 1 M 50.0 k – –
10 ms 1 M 100.0 k 1 M 100.0 k 1 M 100.0 k – –
20 ms 1 M 200.0 k 1 M 200.0 k 1 M 200.0 k – –
50 ms 1 M 500.0 k 1 M 500.0 k 1 M 500.0 k – –
100 ms 1 M 1.0 M 1 M 1.0 M 1 M 1.0 M 1 M 1.0 M 1 M 1.0 M
200 ms 1 M 2.0 M 1 M 2.0 M 1 M 2.0 M 1 M 2.0 M 1 M 2.0 M
500 ms 1 M 5.0 M 1 M 5.0 M 1 M 5.0 M 1 M 5.0 M 1 M 5.0 M
1 s 1 M 10.0 M 1 M 10.0 M 1 M 10.0 M 1 M 10.0 M 1 M 10.0 M
2 s 1 M 20.0 M 1 M 20.0 M 1 M 20.0 M 1 M 20.0 M 1 M 20.0 M
3 s 500 k 15.0 M 1 M 30.0 M 1 M 30.0 M 1 M 30.0 M 1 M 30.0 M
4 s 500 k 20.0 M 1 M 40.0 M 1 M 40.0 M 1 M 40.0 M 1 M 40.0 M
5 s 500 k 25.0 M 1 M 50.0 M 1 M 50.0 M 1 M 50.0 M 1 M 50.0 M
6 s 200 k 12.0 M 500 k 30.0 M 1 M 60.0 M 1 M 60.0 M 1 M 60.0 M
10 s 200 k 20.0 M 500 k 50.0 M 1 M 100.0 M 1 M 100.0 M 1 M 100.0 M
20 s 100 k 20.0 M 200 k 40.0 M 500 k 100.0 M 1 M 200.0 M 1 M 200.0 M
30 s 50 k 15.0 M 100 k 30.0 M 200 k 60.0 M 500 k 150.0 M 1 M 300.0 M
1 min 20 k 12.0 M 50 k 30.0 M 100 k 60.0 M 200 k 120.0 M 500 k 300.0 M
2 min 20 k 24.0 M 20 k 24.0 M 50 k 60.0 M 200 k 240.0 M 200 k 240.0 M
3 min 10 k 18.0 M 20 k 36.0 M 50 k 90.0 M 100 k 180.0 M 200 k 360.0 M
4 min 10 k 24.0 M 20 k 48.0 M 20 k 48.0 M 100 k 240.0 M 200 k 480.0 M
5 min 5 k 15.0 M 10 k 30.0 M 20 k 60.0 M 50 k 150.0 M 100 k 300.0 M
6 min 5 k 18.0 M 10 k 36.0 M 20 k 72.0 M 50 k 180.0 M 100 k 360.0 M
10 min 2 k 12.0 M 5 k 30.0 M 10 k 60.0 M 20 k 120.0 M 50 k 300.0 M
12 min 2 k 14.4 M 5 k 36.0 M 10 k 72.0 M 20 k 144.0 M 50 k 360.0 M
30 min 1 k 18.0 M
2 k 36.0 M 5 k 90.0 M 10 k 180.0 M 20 k 360.0 M
1 hour 500 18.0 M 1 k 36.0 M 2 k 72.0 M 5 k 180.0 M 10 k 360.0 M
2 hour 200 14.4 M 500 36.0 M 1 k 72.0 M 2 k 144.0 M 5 k 360.0 M
3 hour 200 21.6 M 200 21.6 M 500 54.0 M 2 k 216.0 M 2 k 216.0 M
4 hour 100 14.4 M 200 28.8 M 500 72.0 M 1 k 144.0 M 2 k 288.0 M
5 hour 100 18.0 M 200 36.0 M 500 90.0 M 1 k 180.0 M 2 k 360.0 M
6 hour 100 21.6 M 200 43.2 M 200 43.2 M 1 k 216.0 M 2 k 432.0 M
8 hour 50 14.4 M 100 28.8 M 200 57.6 M 500 144.0 M 1 k 288.0 M
10 hour 50 18.0 M 100 36.0 M 200 72.0 M 500 180.0 M 1 k 360.0 M
12 hour 50 21.6 M 100 43.2 M 200 86.4 M 500 216.0 M 1 k 432.0 M
1 day 20 17.2 M 50 43.2 M 100 86.4 M 200 172.8 M 500 432.0 M
2 day 10 17.2 M 20 34.5 M 50 86.4 M 100 172.8 M 200 345.6 M
3 day 5 12.9 M 10 25.9 M 20 51.8 M 50 129.6 M 100 259.2 M
4 day 5 17.2 M 10 34.5 M 20 69.1 M 50 172.8 M 100 345.6 M
5 day 5 21.6 M 10 43.2 M 20 86.4 M 50 216.0 M 100 432.0 M
Appendix 1 Relationship between the Time Scale, Record Length, and Sample Rate
