SD Recording
Display Channel of Slot 1
None CH1_1 CH1_1
CH5
CH1_1
CH1_2
CH1_1
CH1_2
CH5
CH1_1
CH2_1
CH1_1
CH2_1
CH5
CH1_1
CH1_2
CH2_1
CH2_2
CH1_1
CH1_2
CH2_1
CH2_2
CH5
Display
Channel
of Slot 2
None 5 G 2 G 1 G 2 G 1 G 1 G 500 M 1 G 500 M
CH3 5 G 2 G 1 G 2 G 1 G 1 G 500 M 1 G 500 M
CH3, CH6 2 G 1 G 1 G 1 G 1 G 1 G 500 M 1 G 500 M
CH3, CH4 2 G 1 G 1 G 1 G 1 G 1 G 500 M 1 G 500 M
CH3, CH4, CH6 1 G 500 M 500 M 500 M 500 M 500 M 500 M 500 M 500 M
Maximum Record Length When a 4-CH Module Is Not Installed in Slot 1 and Slot 2
Not SD Recording
Display Channel of Slot 1
None CH1 CH1
CH5
CH1
CH2
CH1
CH2
CH5
Display
Channel
of Slot 2
None 100 M 100 M 50 M 50 M 25 M
CH3 100 M 100 M 50 M 50 M 25 M
CH3, CH6 50 M 50 M 50 M 50 M 25 M
CH3, CH4 50 M 50 M 50 M 50 M 25 M
CH3, CH4, CH6 25 M 25 M 25 M 25 M 25 M
SD Recording
Display Channel of Slot 1
None CH1 CH1
CH5
CH1
CH2
CH1
CH2
CH5
Display
Channel
of Slot 2
None 5 G 5 G 2 G 2 G 1 G
CH3 5 G 5 G 2 G 2 G 1 G
CH3, CH6 2 G 2 G 2 G 2 G 1 G
CH3, CH4 2 G 2 G 2 G 2 G 1 G
CH3, CH4, CH6 1 G 1 G 1 G 1 G 1 G
Maximum Number of History Waveform Acquisitions in Scope
Mode
Record Length With 4-CH Module Without 4-CH Module
10 k 1000 1000
25 k 528 1000
50 k 263 528
100 k 105 263
250 k 52 105
500 k 24 52
1 M 9 24
2.5 M 4 9
5 M 1 4
10 M 1 1
25 M 1 1
50 M 1 1
100 M – 1
Appendix 3 Maximum Record Length and Maximum Number of Acquisitions
