YOKOGAWA DL350 User Manual

4-73
IM DL350-17EN
Commands
1
2
3
4
5
App
Index
:CHANnel<x>:VOLTage?
Function Queries all settings of a module that can measure
analog voltage.
Syntax
:CHANnel<x>:VOLTage?
Description For the 720254 (4CH 1M16), the command
applies to the sub channels.
:CHANnel<x>[:VOLTage]:BWIDth
Function Sets or queries the bandwidth limit of a module
that can measure analog voltage.
Syntax
:CHANnel<x>[:VOLTage]:BWIDth {FULL|
<Frequency>}
:CHANnel<x>[:VOLTage]:BWIDth?
<x> = 1 to 4
Example
:CHANNEL1:VOLTAGE:BWIDTH FULL
:CHANNEL1:VOLTAGE:BWIDTH?
-> :CHANNEL1:VOLTAGE:BWIDTH FULL
Description
List of Frequency Settings per Voltage
Measurement Module Type
Type Frequency Settings
720250 500 Hz, 5 kHz, 50 kHz, 500 kHz
701261
When the input coupling is not set to TC
40 Hz, 400 Hz, 4 kHz
When the input coupling is set to TC
2 Hz, 8 Hz, 30 Hz
701262
When the input coupling is not set to TC
40 Hz, 400 Hz, 4 kHz, AUTO
When the input coupling is set to TC
2 Hz, 8 Hz, 30 Hz
701265 2 Hz, 8 Hz, 30 Hz
720268 400 Hz, 4 kHz, 40 kHz, AUTO
720266 0.1 Hz, 1 Hz, 8 Hz
701275 40 Hz, 400 Hz, 4 kHz, AUTO
720211
10 kHz, 20 kHz, 40 kHz, 80 kHz, 160 kHz,
320 kHz, 640 kHz, 1.28 MHz, 2 MHz
720254
6.25 Hz, 12.5 Hz, 25 Hz, 50 Hz, 100 Hz,
200 Hz, 400 Hz, 800 Hz, 1.6 kHz, 3.2 kHz,
6.4 kHz, 12.8 kHz, 40 kHz
:CHANnel<x>[:VOLTage]:COUPling
Function Sets or queries the input coupling of a module
that can measure analog voltage.
Syntax
:CHANnel<x>[:VOLTage]:COUPling {AC|
DC|GND|ACRMS|DCRMS|TC|ACCL}
:CHANnel<x>[:VOLTage]:COUPling?
<x> = 1 to 4
Example
:CHANNEL1:VOLTAGE:COUPLING DC
:CHANNEL1:VOLTAGE:COUPLING?
-> :CHANNEL1:VOLTAGE:COUPLING DC
Description 701250, 701251, 701255, 720210, 720211,
720250: {AC|DC|GND}
701260, 701267, 720268:
{AC|DC|GND|ACRMS|DCRMS}
701261, 701262: {AC|DC|GND|TC}
701265, 720266: {DC|GND|TC}
701275: {AC|DC|GND|ACCL}
:CHANnel<x>[:VOLTage]:DOCancel?
Function Queries all DC offset cancellation settings of a
voltage measurement module.
Syntax
:CHANnel<x>[:VOLTage]:DOCancel?
:CHANnel<x>[:VOLTage]:DOCancel:EXECu
te
Function Executes DC offset canceling on a voltage
measurement module.
Syntax
:CHANnel<x>[:VOLTage]:DOCancel:
EXECute
<x> = 1 to 4
Example
:CHANNEL1:VOLTAGE:DOCANCEL:EXECUTE
Description This command is valid when any of the following
modules is installed and the input coupling is set
to DC.
720211 (HS100M12), 720250 (HS10M12),
720254 (4CH 1M16)
:CHANnel<x>[:VOLTage]:DOCancel:MODE
Function Sets or queries the on/off status of DC offset
canceling of voltage measurement modules.
Syntax
:CHANnel<x>[:VOLTage]:DOCancel:
MODE {<Boolean>}
:CHANnel<x>[:VOLTage]:DOCancel:MODE?
<x> = 1 to 4
Example
:CHANNEL1:VOLTAGE:DOCANCEL:MODE 1
:CHANNEL1:VOLTAGE:DOCANCEL:MODE?
-> :CHANNEL1:VOLTAGE:DOCANCEL:MODE 1
4.6 CHANnel Group
