IM 1C22H1-01E
7-3
7. BRAIN TERMINAL BT200 OPERATION
7.2.3 Calling Up Menu Addresses Using the Operating Keys
DATA DIAG PRNT ESC
PARAM
A60:SELF CHECK
GOOD
CODE CAPS CLR ESC
––WELCOME––
BRAIN TERMINAL
ID: BT200
check connection
push ENTER key
UTIL FEED
esc
PARAM
01:MODEL
EJA118-DM
02:TAG NO.
YOKOGAWA
03:SELF CHECK
GOOD
OK
STARTUP
SCREEN
MENU
SCREEN
SETUP
SCREEN
INITIAL
DATA
SCREEN
PARA-
METER
SCREEN
(HOME MENU SCREEN) (SET MENU SCREEN) (ADJ MENU SCREEN)
See “BT200 Instruction Manual” for details
concerning uploading and downloading parameters
and printouts (BT200-P00).
(UTIL)
(SET)
(ESC)
HOME SET ADJ ESC
(ADJ)
The utility screen contains the
following items.
1. BT200 ID settings
2. Security code settings
3. Switching language of messages
(Japanese or English)
4. LCD contrast setting
5. Adjusting printout tone
(BT200-P00 only)
FUNC
1.MENU
2.UPLOAD TO BT200
3.DOWNLOAD TO INST
4.PRINT ALL DATA
HOME SET ADJ ESC
MENU
A.DISPLAY
B.SENSOR TYPE
HOME SET ADJ ESC
MENU
C.SETTING
D.AUX SET 1
E.AUX SET 2
H:AUTO SET
HOME SET ADJ ESC
MENU
J.ADJUST
K.TEST
M.MEMO
P:RECORD
DATA DIAG PRNT ESC
DATA DIAG PRNT ESCDATA DIAG PRNT ESC DATA DIAG PRNT ESC
PARAM
C60:SELF CHECK
GOOD
PARAM
C22:HIGH RANGE
100 kPa
DATA DIAG PRNT ESC
PARAM
J60:SELF CHECK
GOOD
PARAM
J10:ZERO ADJ
0.0 %
J11:ZERO DEV
22.2 %
J20:EXT. ZERO ADJ
ENABLE
SET
C10:TAG NO.
YOKOGAWA
YOKOGAWA
F0709.EPS
DATA DIAG PRNT ESC
PARAM
A10:OUTPUT(%)
50.0 %
A11:ENGR, OUTPUT
20.0 M
A20:AMP TEMP
24.5 deg C
DATA DIAG PRNT ESC
PARAM
C10:TAG NO.
YOKOGAWA
C20:PRESS UNIT
kPa
C21:LOW RANGE
0 kPa
PARAM
A21:CAPSULE TEMP
26.5 deg C
UTILITY
1.ID
2.SECURITY CODE
3.LANGUAGE SELECT
4.LCD CONTRAST
5.PRINTER ADJUST
To Next Page
