YOKOGAWA DY080 User Manual

5-5
IM 01F06A00-01E
5. PARAMETER SETUP
(5) Item E : Detector Setup
These items are for detector that has been already set before.
T050306.EPS
E00
E10
E20
E30
E40
E41
E50
E60
W
W
W
W
W
W
R
E40 0 to 5
(1)
(0)
(0)
(0)
68.6
D
D
D
D
D
L
L
L
L
METER SETUP
NOMINAL SIZE
BODY TYPE
SENSOR TYPE
K-FACT UNIT
K-FACTOR
DETECTOR No.
SELF CHECK
15mm (0)
25mm (1)
40mm (2)
50mm (3)
80mm (4)
100mm (5)
150mm (6)
200mm (7)
250mm (8)
300mm (9)
-------- (10)
Standard (0)
High Pressure (1)
Low Flow Unit (1) (2)
Low Flow Unit (2) (3)
-------- ( 1 )
Standard (0)
High Temperature (1)
Low Temperature (2)
P/l (0)
P/Usgal (1)
P/Ukgal (2)
0.00001 to 32000
16 characters
GOOD
ERROR
Menu E (Detector setup)
Selection of Nominal Size
Selection of Body Type
Selection of Sensor Type
Selection of K-factor Unit
K-factor value of 15 deg C
Detector number
Self-diagnostic message
Item Name R / W Data Range Unit Remark
Initial
value
Disp. U / D
Decimal
point
FU : Flow unit
A value in “( )” is the data corresponding to the indicator.
