3. Cabling
3-26
TI 32P01J10-01EN
SED4D Digital Terminal Board
F030417.ai
Functional grounding
terminal
(Terminal screw: M4)
Figure SED4D Ground Cable Connection
SWD2D Digital Terminal Board
F030418.ai
Protective conductor
terminal
(Terminal screw: M4)
Figure SWD2D Ground Cable Connection
TIP
Terminal Boards such as A2BM4, SBA4D, SBT4D, SBR4D, SBD2D, SBD3D, SBD4D and S1BB4D don’t have a
grounding terminal.
Oct. 5, 2018-00
To Next Page
