3. Cabling
3-48
TI 32P01J10-01EN
3.6.3 Connecting Signal Cables to I/O Modules
Pressure Clamp Terminal
CH1
CH2
CH16
Example of Analog module SAI143
Signal cable
F030602.ai
NC
(not connected)
Figure I/O Module with Pressure Clamp Terminal
Dual-redundant Pressure Clamp Terminal
CH1
CH2
CH16
Example of Analog module SAI143
NC
(not connected)
Signal cable
F030603.ai
Figure I/O Module with Dual-redundant Pressure Clamp Terminal
Nov. 27, 2015-00
