2. Transportation, Storage and Installation
2-33
TI 32P01J10-01EN
Mar. 29, 2019-00
Example of Mounting an SCU for N-IO and N-IO Nodes in a Cabinet
Temperature conditions
In this example, the ambient temperature is assumed to be the following.
Cabinet ambient temperature 40 °C or less
Maximum numbers of units that can be mounted in case of this example
Type Model Number of units that can be mounted per side
SCU
S2SC70S/S2SC70D
(Except for S2SC70-S)
Up to 1
NIU S2NN30D Up to 1
IOBP S2BN1D Up to 6 (2 rows × 3 shelves)
Heat-generating devices other than the above shall not be mounted in the cabinet.
Mounting conditions
• The SCU on the top shelf shall be mounted with a 100-mm or more space from the cabinet
ceiling.
• A 1-unit (= 44.45 mm) or more space shall be provided between NIU and IOBP.
• A circulation fan unit shall be mounted on the shelf below the SCU with a 1-unit space. A
1-unit or more space shall be provided under the circulation fan unit.
• Suitable length of signal cables and power cables should be used.
To Next Page
