YOMANI ML/XR
OWNER MANUAL
6 unrestricted
last updated 3 May 16 document release 2.2 ymn_terminal.fm
Figure 4. YOMANI ML – back/base view
1 connector for contactless reader
2 rating plate
3 RS-232 serial socket
4SAM-slot cover
5 USB device socket
6 Ethernet socket
7 Reset button
Figure 5. YOMANI XR – back/base view
1 connector for contactless reader
2 rating plate
3 RS-232 serial socket
