Yomani ML - Communications Interface Boards; Figure 10. Printer; Figure 11. Communications Interface Boards

YOMANI ML/XR
OWNER MANUAL
10 unrestricted
last updated 3 May 16 document release 2.2 ymn_terminal.fm
Communications interface boards
Figure 11. Communications Interface boards
PSTN
A PSTN communications interface board can be fitted to a YOMANI XR to
support communications over an analogue telephone network
wireless communications
A wireless communications interface board can be fitted to a YOMANI XR with
built-in antenna.
– WiFi/Bluetooth, for short and mid-range point to point wireless
communications
• WiFi, IEEE 802.11 b/g/n
• Bluetooth class 1.5
– 2G (GSM/GPRS/Edge) 850-900-1800-1900 MHz
– 3G (HSDPA/UMTS)
Two versions of the 3G interface board are available, for:
Figure 10. Printer
1 release button for paper-roll cover
2 paper-roll cover
2
1
