YOMANI ML/XR
OWNER MANUAL
8 unrestricted
last updated 3 May 16 document release 2.2 ymn_terminal.fm
2 USB host connector to fit USB host socket on adaptor or ePOS equipment
3USB cable
4 USB device connector to fit USB device socket on terminal
Figure 8. USB cable with clip
1 USB device connector to fit USB device socket on terminal
2USB cable (3m)
3 USB host connector with clip, to fit powered USB host socket on ePOS
equipment
4 powered USB host socket (12V) on ePOS equipment
4
1
2 3
