York SOLUTION XTO Series - FIGURE 170 - Installing Welded Bevel Seal Filter

JOHNSON CONTROLS
106
FORM 102.20-N1
ISSUE DATE: 7/06/2016
SECTION 3 - HANDLING, STORAGE, AND INSTALLATION
AIRFLOW
FIGURE 170 - INSTALLING WELDED BEVEL SEAL FILTER
LD06646a
Visual Control Clamp
(Adjust bolt Head Flush
With Clamp)
Spring
Ductwork
Cell Side
Media Pack
Gasket
Cell Side
Bevel Seal Frame
Bevel
Recessed Sealing
Surface
Bevel Seal Frame
(Perimeter Extrusion)
