Application Data ‑ continued
TABLE 2 – ELECTRICAL DATA
CHILLER
MODEL
VOLT.
CODE
VOLTAGE
WIRE
AMPACITY
NON‑FUSED
DISCONNECT
SWITCH
MAX
DUAL
ELEMENT
FUSE
SOLU‑
TION
PUMP
FLA
SPRAY
PUMP
FLA
REFRIG
PUMP
FLA
PURGE
PUMP
FLA
ELEC
PANEL
FLA
TOTAL
CURRENT
TOTAL
KW
14SC
-17 200/208V-3PH-60Hz 43.7 60A/240V 60/250V 22 — 6.2 1.7 5 34.9 7.4
-28 230-3PH-60Hz 39.4 60A/240V 50/250V 20 — 5.6 1.5 4.3 31.4 7.4
-50 380V-3PH-50Hz 22.3 30A/480V 30/600V 11.2 — 3.1 0.9 2.6 17.8 7.5
-46 460V-3PH-60Hz 19.8 30A/480V 25/600V 10 — 2.8 0.8 2.2 15.8 7.4
16SL, 17S
18S
-17 200/208V-3PH-60Hz 76.7 100A/240V 125A/250V 36.8 12 12 1.7 5 67.5 15.5
-28 230-3PH-60Hz 75.8 100A/240V 100A/250V 36.8 12 12 1.5 4.3 66.6 15.5
-50 380V-3PH-50Hz 41.3 60A/480V 60A/600V 19 7 7 0.9 2.6 36.5 16.2
-46 460V-3PH-60Hz 38 60A/480V 50A/600V 18.4 6 6 0.8 2.2 33.4 15.5
19S
-17 200/208V-3PH-60Hz 94.7 200A/240V 125A/250V 36.8 30 12 1.7 5 85.5 20.1
-28 230-3PH-60Hz 93.8 100A/240V 125A/250V 36.8 30 12 1.5 4.3 84.6 20.1
-50 380V-3PH-50Hz 51.3 60A/480V 60A/600V 19 17 7 0.9 2.6 46.5 21.2
-46 460V-3PH-60Hz 47 60A/480V 60A/600V 18.4 15 6 0.8 2.2 42.4 20.1
NOTES:
1. Incoming wire to chiller must be copper only. Aluminum wiring is not permitted.
2. Lugs in Power Panel will accept incoming wire range of #14 AWG through #1 AWG.
3. Electrical system must be securely guarded.
4. Field wiring must conform to NEC and all other applicable local codes.
