CONDENSER FAN DATA
Quantity 1 1 1
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Drive Direct Drive Direct Drive
No. speeds 1 1 1
Number of motors 1 1 1
Motor HP each 1/2 1/2 1/2
RPM 1090 1090 1090
Nominal total CFM 4200 4200 4200
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 12 x 10 12 x 10 12 x 10
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL40 1VL40 1VL40
Blower Sheave AK74 AK61 AK56
Belt A39 A36 A36
Motor HP each 1-1/2 1-1/2 1-1/2
RPM 1725 1725 1725
Frame size 56 56 56
FILTERS
15” x 20” x 1” or 2” 2 2 2
14” x 25” x 1” or 2” 1 1 1
ZJ036-060 Physical Data (Continued)
Component
Models
ZJ036 ZJ048 ZJ060
Nominal Tonnage 3.0 4.0 5.0
