York ZJ Series Technical Guide

251933-YTG-B-0806
Unitary Products Group 13
XP036-060 Physical Data
Component
Models
XP036 XP048 XP060
Nominal Tonnage 3.0 4.0 5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu) 36200 48500 60900
ARI net capacity (Btu) 35000 46500 58700
EER 11.0 10.8 10.9
SEER 13.0 13.0 13.0
Nominal CFM 1200 1600 2000
System power (KW) 3.25 4.26 5.39
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz) 13-0 13-0 12-0
ARI HEATING PERFORMANCE
47°F capacity rating (MBH) 34800 45000 59000
System power (KW) / COP 3.29(kW) / 3.10 4.06(kW) / 3.25 5.25(kW) / 3.34
17°F capacity rating (MBH 19000 27000 35000
System power (KW) / COP 2.60(kW) / 2.15 3.86(kW) / 2.06 4.76(kW) / 2.15
HSPF (Btu/Watts-hr) 7.70 7.70 7.70
DIMENSIONS (inches)
Length 82-1/4 82-1/4 82-1/4
Width 44-7/8 44-7/8 44-7/8
Height 32-5/8 32-5/8 32-5/8
OPERATING WT. (lbs.) 575 585 590
COMPRESSORS
Type Scroll Scroll Scroll
Quantity 1 1 1
CONDENSER COIL DATA
Face area (Sq. Ft.) 16.88 16.88 16.88
Rows 222
Fins per inch 18 18 18
Tube diameter 3/8 3/8 3/8
Circuitry Type Split-face Split-face Split-face
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 5.06 5.06 5.06
Rows 444
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Circuitry Type Split-face Split-face Split-face
Refrigerant control TXV TXV TXV
http://www.rezine.ne
t
Page 15

York ZJ Series Specifications

General

Brand	York
Model	ZJ Series
Category	Heat Pump
Language	English
