1. Open the back cover of the Charging Station, and install
the adapter with connected power plug as shown in the gure 2 above.
2. Completely connect the charging jack of the adapter to the
jack inside the charging station.
1. Turn on the Power Switch on the side of the product.
2. Correctly match the Charging Pin on the boom of the Main Body to the socket of the Charging Station,
and start the charging.
>> e baery status in the display window blinks and charging starts.
If baery is completely discharged, “Lo” is displayed in the display window.
3. Red, Yellow and Green light will be blinking in order on the display window according to the baery's
charge while the robot is charging and the baery indicator will become steady green when the baery is full.
※ Baery Indicator Color
- Green: Baery is fully charged
- Yellow: Remaining baery is
50% or less
- Red: Remaining baery is
20% or less
[Auto-charge during use]
※ When the baery is low during an operation, this product moves to the charging station and performs auto charging.
Aer the charging is completed, it nishes cleaning the remaining space, and returns to the charging station.
※ When the baery is low, this product is set to return to the starting place of the cleaning.
So if it started from a place other than the charging station, it returns to the place near
the starting place of the cleaning.
※ Charging indicator color on Charging Station
- Red: change to eX500 is in operation away from the charging station, or the connection between eX500 and the
charging station is improperly connected.
- Green Blinking: Recharging
- Green: Recharge completed
e baery is not charged at the time of product purchase.
so it must be fully charged before rst use.
