Zapi AC0 - Page 28

Page 27
AUX
OUTPUT
STOP
ON
RAMP
A3
OUTPUT
BEHAVIOUR ON A SLOPE
BRAKE ON
-Drives the coil of a electromagnetic
brake.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is elapsed
the brake is applied and the 3-
phase bridge is released. Do not
use this combination if the
negative brake is not installed.
BRAKE OFF
-Drives the coil of a electromagnetic
brake.
The truck is not electrically hold on
a slope, but comes down very
slowly; when the time set by
"auxiliary time" parameter is
elapsed, the brake is applied and
the 3-phase bridge is opened.
Do
not use this combination if the
negative brake is not installed.
HYDRO
CONT.
ON
-Drives the coil of a hydraulic
steering contactor.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down very
slowly, till the flat is reached.
HYDRO
CONT.
OFF
-Drives the coil of a hydraulic
steering contactor.
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
EXCL.
HYDRO
ON
-Drives the coil of a hydraulic
steering contactor.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down very
slowly, till the flat is reached.
EXCL.
HYDRO
OFF
-Drives the coil of a hydraulic
steering contactor.
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
