Page - 36/81 AFCZP0BC- COMBIACX & ACEX - User Manual
10.4 Function configuration
10.4.1 Config menu “SET OPTIONS” functions list
To enter the CONFIG MENU’ it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the SET OPTION item appears on the
hand set display. Push the ENTER button.
Opening Zapi Display
ADXT2B ZP1.00
24V 165A 00000
Push ROLL UP + SET UP simultaneously to enter
CONFIG MENU
% ' %
' ' '
The Display will show : SET MODEL
CONFIG MENU
SET MODEL
Press ROLL UP or ROLL DOWN button until SET
OPTIONS menu appear.
% ' '
' ' '
The Display will show : SET OPTIONS
CONFIG MENU
SET OPTIONS
Press ENTER to go in the SET OPTIONS MENU
' % '
' ' '
The Display will show the first OPTION
HOURCOUNTER
RUNNING
Press SET UP or SET DOWN button in order to
modify the OPTION
' ' %
' ' %
The Display will show the new option
HOURCOUNTER
KEYON
Press OUT to exit the menu
' ' '
' % '
The Display will ask “ARE YOU SURE”.
ARE YOU SURE?
YES=ENTER NO=OUT
Press ENTER for YES, or OUT for No
' % '
' ' '
' ' '
' % '
The Display will show : SET OPTIONS
CONFIG MENU
SET OPTIONS
Press OUT again. Display now will show the
opening Zapi menu.
' ' '
' % '
