Page - 74/81 AFCZP0BC- COMBIACX & ACEX - User Manual
12.4 Analysis and troubleshooting of warnings
1) “SLIP PROFILE”
Cause:
There is an error on the choice of the parameters of the slip profile.
Troubleshooting:
Check in the hardware setting menu the value of those parameters.
2) “FORW+BACK”
Cause:
This alarm occurs when both the travel demands (Fwd and Bwd) are active at
the same time.
Troubleshooting:
Check the wiring of the Fwd and Rev travel demand inputs (use the readings in
the TESTER to facilitate the troubleshooting). Check the microswitches for
failures.
A failure in the logic is possible too. So, when you have verified the travel
demand switches are fine working and the wiring is right, it is necessary to
replace the controller.
3) “INCORRECT START”
Cause:
This is a warning for an incorrect starting sequence.
Troubleshooting:
The possible reasons for this alarm are (use the readings in the TESTER to
facilitate the troubleshooting):
A) A travel demand active at key on
B) Presence man sensor active at key on
Check the wirings. Check the micro-switches. It could be also an error
sequence made by the operator. A failure in the logic is possible too; so when
all of the above conditions were checked and nothing was found, replace the
controller.
4) “VACC NOT OK”
Cause:
The test is made at key-on and after 20sec that both the travel demands have
been turned off. This alarm occurs if the ACCELERATOR reading in the
TESTER menu’ is 1,0V higher than PROGRAM VACC min acquisition when
the accelerator is released.
Troubleshooting:
Check the mechanical calibration and the functionality of the potentiometer.
5) “TH. PROTECTION”
Cause:
This alarm occurs when the temperature of the base plate is higher than 85°.
Then the maximum current decreases proportionally with the temperature
increases from 85° up to 105°. At 105° the Current is limited to 0 Amps.
Troubleshooting:
Improve the air cooling of the controller. If the alarm is signalled when the
controller is cold, the possible reasons are a thermal sensor failure or a failure in
the logic card. In this case, it is necessary to replace the controller.
