Zapi ACEX User Manual

AFCZP0BC – COMBIACX & ACEX - User Manual Page - 73/81
Error code Description Effect
Machine status
when the test is
done
Restart
procedure
Drv. Shor. EV1 dri -
MDI CAN 74
EV1 on/off valve drivers shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
Drv. Shor. EV2 -
MDI CAN 74
EV2 on/off valve driver shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
Drv. Shor. EV3 -
MDI CAN 74
EV3 on/off valve driver shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
Pump I NO zero -
MDI CAN 56
Pump chopper current sensor
feedback is out of permitted stby
range
Pump motor stopped start-up, stby pump request
Pump I=0 ever -
MDI CAN 52
Pump current feedback is always
0A even when pump motor is
running
Pump motor stopped pump function pump request
Cont. Drv. Ev1 - MDI
CAN 75
Driver of Ev1 is open, not able to
close
Ev1 stopped during Ev1
function
valve Ev1 request
Cont. Drv. Ev2 - MDI
CAN 75
Driver of Ev2 is open, not able to
close
Ev2 stopped during Ev2
function
valve Ev2 request
Cont. Drv. Ev3 - MDI
CAN 75
Driver of Ev3 is open, not able to
close
Ev3 stopped during Ev3
function
valve Ev3 request
Pump Vacc not OK -
MDI CAN 89
The pump accelerator value is
higher than the minimum value
recorded, and the lift/lower
switches are open
Pump stopped Continuous Pump request
Sens. Mot. Temp.
KO - MDI CAN 67
The motor temperature sensor is
damaged
Performance highly
reduced
Continuous Key-on recycle
Vacc out range -
MDI CAN 85
The voltage on CNC#4 is out of the
parameters range
Traction stopped Continuous Program VACC
Stall rotor - MDI
CAN 11
The traction rotor is stuck or the
encoder is not working
Traction stopped Continuous Key-on recycle
EVP driver open -
MDI CAN 48
The EVP driver isdamaged or the
EVP coil impedance is too low
EVP stopped Continuous Key-on recycle
Many pump reqs -
MDI CAN 49
There are too many pump requests
at the same time
Pump stopped Continuous Remove request
Pump inc start - MDI
CAN 79
Incorrect pump starting sequence Pump stopped start-up, stand-
by
Pump request
Pump Vacc range -
MDI CAN 90
The voltage on CNC#9 is out of the
parameters range
Pump stopped, EVP
stopped
Continuous Pump request
Param. Restore -
MDI CAN 13
A parameters set restore was
made since the last keyoff
No effect start-up Traction, pump or
EVP request
Wait mot. P. still -
MDI CAN 63
The software waits for the motor
pump to stop
Valve, pump, traction
stopped, LC opened,
Eb applied
start-up None
