Page - 10/81 AFCZP0BC- COMBIACX & ACEX - User Manual
3.5 Speed feedback
The motor control is based upon the motor speed feedback (sensored software).
The speed transducer is an incremental encoder, with two phases shifted at 90°.
The encoder can be of different types :
- power supply: +12V / +5V;
- electric output: open collector ( NPN ), push-pull.
COMBIACX / ACEX can also operate without encoder, this using a sensorless
control.
This solution has to be discussed with Zapi technicians.
4 Note (1): The encoder resolution and the motor poles pair (the controller can
handle), is specified in the home page display of the handset showing following
headline:
ADXZ2A ZP1.00
That means:
ADXZ= COMBIACX Zapi controller
2 = motor’s poles pair number
A = 32 pulses/rev encoder
The encoder resolution is given by the second-last letter in the following list:
A = 32 pulses/rev
K = 48 pulses/rev
B = 64 pulses/rev
C = 80 pulses/rev
