Page - 40/81 AFCZP0BC- COMBIACX & ACEX - User Manual
7) The display will show: SET BATTERY TYPE
BATTERY TYPE
24V
8) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
% ' '
% ' '
9) The desired parameter appears
TROTTLE 0 ZONE
3%
10) Press SET UP or SET DOWN button to modify
the adjustment
' ' %
' ' %
TROTTLE 0 ZONE
7%
11) Press OUT
' ' '
' % '
12) Press ENTER to confirm
' % '
' ' '
13) Repeat the same from 5 to 12 points for the
other adjustments
1) SET BATTERY TYPE
Selects the nominal battery voltage.
2) ADJUST BATTERY
Fine adjustment of the battery voltage measured by the controller.
3) THROTTLE 0 ZONE
Establishes a dead-band in the accelerator input curve.
4) THROTTLE X POINT
This parameter, together with the THROTTLE Y POINT, changes the
characteristic of the accelerator input curve : when the accelerator is de-
pressed to X point per cent, the corresponding truck speed is Y point per cent of
the Maximum truck speed. The relationship between the accelerator position
and the truck speed is linear between the THROTTLE 0 ZONE and the X point
and also between the X point and the maximum accelerator position but with
two different slopes.
5) THROTTLE Y POINT
This parameter, together with the THROTTLE X POINT, changes the
characteristic of the accelerator input curve (see also paragraph 13.5): when the
accelerator is de-pressed to X point per cent, the corresponding truck speed is
Y point per cent of the Maximum truck speed. The relationship between the
accelerator position and the truck speed is linear between the THROTTLE 0
ZONE and the X point and also between the X point and the maximum
accelerator position but with two different slope.
6) BAT. MIN ADJ.
Adjust the lower level of the battery charge table (Level 0 to 9).
7) BAT. MAX ADJ.
Adjust the upper level of the battery charge table (Level 0 to 9).
