Zapi ADPZP0CC - Connector CND (4 poles); Connector CNE (8 poles); Connector CNF (10 poles)

Page - 16/36 ADPZP0CC - MHYRIO FLASH CONTROLLER - User Manual
C3 GND Negative supply
C4 AN2 Analog input N°2
C5 +12 +12V supply
C6 +12 +12V supply
5.4 Connector CND: ZAPI Minifit 4 poles
D1 GND Encoder negative supply
D2 A Encoder phase A input
D3 +12 Encoder positive supply
D4 B Encoder phase B input
5.5 Connector CNE: ZAPI Minifit 8 poles
E1 PCLRXD Serial communication interface
E2 NCLRXD Serial communication interface
E3 PCLTXD Serial communication interface
E4 NCLTXD Serial communication interface
E5 GND Negative supply
E6 +12 +12V supply
E7 BOOT Flash memory bootstrap
E8 GND Flash memory bootstrap
5.6 Connector CNF: ZAPI Minifit 10 poles
F1 R Resistance
F2 NEV3 Negative of ON/OFF electrovalve N°3
F3 NEV2 Negative of ON/OFF electrovalve N°2
F4 NEV1 Negative of ON/OFF electrovalve N°1
F5 PEV Positive of ON/OFF electrovalve N°3
F6 Z Zero
F7 AS1 Analog select #1
F8 AS2 Analog select #2
F9 PEV Positive of ON/OFF electrovalve N°1
F10 PEV Positive of ON/OFF electrovalve N°2
AS1 and AS2 select the software versions when more than one Mhyrio is
installed on the same truck. There are 9 possibilities:
Z................................. OPEN
Z.........................................R
Z......................................... Z
OPEN......................... OPEN
OPEN.................................R
