Page - 20/36 ADPZP0CC - MHYRIO FLASH CONTROLLER - User Manual
7 PROGRAMMING & ADJUSTMENTS USING
DIGITAL CONSOLE
7.1 Adjustments via console
Adjustment of Parameters and changes to the controller’s configuration are made
using the Digital Console. Mhyrio Flash has not an external connector for console
connection. The Console must be connected to the console connector of another
ZAPI product that communicates with MHYRIO FLASH via CAN-BUS line.
U Pay attention to the polarity of the Console Connector when connecting to
the controller. The bevel on the connector should be uppermost.
7.2 Description of console and connection
Digital consoles used to communicate with MHYRIO FLASH controllers must be
fitted with EPROM CK ULTRA, minimum “Release Number 3.06”.
