Zapi ADPZP0CC - DESCRIPTION OF THE CONNECTORS; Connector CNA (22 poles); Connector CNB (6 poles); Connector CNC (6 poles)

ADPZP0CC - MHYRIO FLASH CONTROLLER - User Manual Page - 15/36
5 DESCRIPTION OF THE CONNECTORS
5.1 Connector CNA: ZAPI Minifit 22 poles
A1 I2 Digital Input N° 2
A2 I3 Digital Input N° 3
A3 I4 Digital Input N° 4
A4 I5 Digital Input N° 5
A5 I6 Digital Input N° 6
A6 PEV Positive supply of digital input devices
A7 I7 Digital Input N° 7
A8 OPT I8 Digital Input N° 8
A9 GND Negative supply
A10 CANH CAN high signal
A11 CANT2 CAN high signal output
A12 I1 Digital Input N°1
A13 PEVS Positive of electrovalves (safety)
A14 PEV Positive supply of digital input devices
A15 PEV Positive supply of digital input devices
A16 PEV Positive supply of digital input devices
A17 PEV Positive supply of digital input devices
A18 GND Negative supply
A19 GND Negative supply
A20 GND Negative supply
A21 GND Negative supply
A22 CANT1/CANL CAN low signal output/CAN low signal
5.2 Connector CNB: ZAPI Minifit 6 poles
B1 CANH CAN high signal
B2 KEY Key input
B3 PEVS Positive of electrovalves (safety)
B4 CANL CAN low signal
B5 -BATT Negative supply
B6 PAUX Positive supply for electrovalves
5.3 Connector CNC: ZAPI Minifit 6 poles
C1 AN1 Analog input N°1
C2 GND Negative supply
