7.7 Description of the tester function
The most important input or output signals can be measured in real time using
the TESTER function of the console. The Console acts as a multimeter able to
read voltage, current and temperature. The following listing shows the
measurements that may be made:
1) DIGITAL INPUT 1
It indicates the state of the digital input 1 (CNA12). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
2) DIGITAL INPUT 2
It indicates the state of the digital input 2 (CNA1). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
3) DIGITAL INPUT 3
It indicates the state of the digital input 3 (CNA2). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
4) DIGITAL INPUT 4
It indicates the state of the digital input 4 (CNA3). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
5) DIGITAL INPUT 5
It indicates the state of the digital input 5 (CNA4). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
6) DIGITAL INPUT 6
It indicates the state of the digital input 6 (CNA5). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
7) DIGITAL INPUT 7
It indicates the state of the digital input 7 (CNA7). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
8) DIGITAL INPUT 8
It indicates the state of the digital input 8 (CNA8). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
9) EV #1
It indicates the state of the electrovalve 1 (CNG8). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
10) EV #2
It indicates the state of the electrovalve 2 (CNG7). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
11) EV #3
It indicates the state of the electrovalve 3 (CNG6). Options:
- ON = active entry of closed switch (equal to battery positive potential)
- OFF = inactive entry of open switch (equal to GND potential)
