14) MAX EV6
This parameter adjusts the maximum current of valve 6, if it is set as
proportional (see "set options menu").
15) MAX EV7
This parameter adjusts the maximum current of valve 7, if it is set as
proportional (see "set options menu").
16) MAX EV8
This parameter adjusts the maximum current of valve 8, if it is set as
proportional (see "set options menu").
17) GROUP1 ACC DELAY
Lift/lowering valves current acceleration delay: this parameter sets the valve
1 and 2 current ramp, to change from 0 A to operating current.
18) GROUP2 ACC DELAY
Group 2 valves current acceleration delay: this parameter sets the valve 3
and 4 (group 2) current ramp, to change from 0 A to operating current.
19) GROUP3 ACC DELAY
Group 3 and 4 valves current acceleration delay: this parameter sets the
valve 5 and 6 (group 3), 7 and 8 (group 4) current ramp, to change from 0 A
to operating current.
20) GROUP1 DEC DELAY
Lift/lowering valves current deceleration delay: this parameter sets the valve
1 and 2 closing ramp, to change the coil current from operating current to 0
A.
21) GROUP2 DEC DELAY
Group 2 valves current deceleration delay: this parameter sets the valve 3
and 4 (group 2) closing ramp, to change the coil current from operating
current to 0 A.
22) GROUP3 DEC DELAY
Group 3 and 4 valves current deceleration delay: this parameter sets the
valve 5 and 6 (group 3), 7 and 8 (group 4) closing ramp, to change the coil
current from operating current to 0 A.
7.6 Adjustments table
PARAMETERS PROGRAMMED LEVEL
UNIT 0 1 2 3 4 5 6 7 8 9
GROUP1
ACC DELAY
sec. 0.5 0.7 0.9 1.1 1.4 1.6 1.8 2.0 2.3 2.5
GROUP2
ACC DELAY
sec. 0.25 0.35 0.45 0.55 0.70 0.80 0.90 1.00 1.15 1.25
GROUP3
ACC DELAY
sec. 0.25 0.35 0.45 0.55 0.70 0.80 0.90 1.00 1.15 1.25
GROUP1
DEC DELAY
sec. 0.5 0.7 0.9 1.1 1.4 1.6 1.8 2.0 2.3 2.5
GROUP2
DEC DELAY
sec. 0.25 0.35 0.45 0.55 0.70 0.80 0.90 1.00 1.15 1.25
GROUP3
DEC DELAY
sec. 0.25 0.35 0.45 0.55 0.70 0.80 0.90 1.00 1.15 1.25
