2. Description of the Zaptec Pro system
Use all available capacity
The power is shared dynamically across all the charging
stations. Enables over 100 electric vehicles to be charged
in one day, via a single 63A* circuit breaker. Charge at up
to 22kW on all charging stations.
Unique scope for scaling with a single circuit
andpower cable
Communication between the charging stations and the
cloud solution passes through the same power cable.
This shared infrastructure makes it possible to start
with a few charging stations and expand the system as
and when necessary. Scaling an existing installation will
therefore not require any extra work or investment in
electrical infrastructure.
Fair use through RFID or Zaptec App
A built-in electricity meter accurately records
energy consumption, which can then be allocated
toauthorised users.
* With three-phase connection and typical charging usage over 24 hours.
Safety in accordance with the highest standards
Fully-rated Type 2 charging socket, circuit breaker,
electronic earth fault protection and temperature sensors
are built into the charging station. This ensures safety
forboth the user and the power grid.
Future-proof and intelligent charging solution
Combines power electronics, built-in software and a
cloud-hosted portal for configuration, monitoring and
control. The solution is future-proof, with software updates
delivered over-the-air to the charging station.
