NOMAD LAYOUT Meters Screens

Card Track Home Screen

Card Tracks with Output Buses 1 and 2

Output Bus with Inputs

Virtual Fader Home Screen

Red Record Enabled Indicators - shows which tracks will be recorded

Yellow ISO Attenuation Enabled

Line level inputs 7 through 10 with virtual fader control

Yellow Strike Through – Represents that

these tracks will not be recorded
