Operation manual of ZBL-R800, ZBL-R630, ZBL-C310A
Hotline: (86)010-51290405 Fax: (86)010-51290406
23
Figure 3-8 Object number setting
The definition of parameters and methods of setting are as following.
1. Object No.
Object No. is combined either by six digtals, or mixed group of letters
and symbols. The default object No. is 000000. After rebooting, when
entering into parameter setting interface, the last digit of last object No.
(stored) pulsing one is the default object No. (the increasing order is
based on soft keyboard order shown in figure3-8 until last symbol
“/” ). For example, if the last stored object is 300009, when reentering
into parameter setting interface, default object No. is 30000A.
In the figure 3-7 interface, pressing【a】,【b】to shift cursor to Obj.
No, then press 【ENTER】 to the interface as figure 3-8, the cursor is
below the first character of object No. and pressing【_】,【`】adjusts
cursor to any character for modification .Then pressing 【b】to
display soft keyboard below, the cursor occurring in the upper corner
of the soft keyboard, to select input word by【a】,【b】,【_】,【`】,and
after pressing 【ENTER】, it will occurs in the cursor position of
object No., at the same time, cursor in object No. will automatically
move down to the next position and cursor in soft keyboard will
disappear. If continuing change, please repeat the operation above.
After the completion of modification, pressing【SAVE】key to store
this No., then cursor in the No. will disappear and will go back to
parameter setting interface automatically.
