Operation manual of ZBL-R800, ZBL-R630, ZBL-C310A
Hotline: (86)010-51290405 Fax: (86)010-51290406
46
maximum, minimum and average value of this object. Pressing
【ENTER】key to enter into interface as shown in figure3-33 for the
stored data.
The options in the figure have following meanings:
NO. —serial number
Dia—tested diameter value, if no data, no diameter test.
T—thickness value of cover, if there is tested diameter value in
Dia., then T is the thickness value measure by “testing diameter”
△— the poor between tested diameter and default diameter.
Sx—the tested thickness value is exceed or not, excessive with
“*”, the other with blank.
If the number of stored data is more than one screen, please press【a】
or 【b】 key to turn to next page (the top of upward page-turning is
the statistical interface), when in the interface, pressing【BACK】to go
back to the interface in figure3-31.
3.4.4.2. Grid data check
Pressing【ENTER】key on the interface in figure 3-33(a), and entering
into grid data display interface in figure3-33(b), pressing【a】,【b】,
【_】,【`】 for page-turning check.
(a) (b)
Figure 3-33 Grid data check
In any interface during data display, pressing 【BACK】key can go
back to interface shown in figure3-33(a), and pressing【MENU】to go
back to main menu.
