Routine Maintenance
Cleaning Schedule and Procedures
122
P1009874-001 Xi4 User Guide 3/12/09
Transmissive Media Sensor Locations
The locations of the upper and lower transmissive media sensors are shown in Figure 17 and
Figure 18.
Figure 17 • Upper Media Sensor
Figure 18 • Lower Media Sensor
1
Upper media sensor
1
Lower media sensor
