Zebra 110Xi4 User Manual

Troubleshooting
LCD Error Messages
136
P1009874-001 Xi4 User Guide 3/12/09
There is not enough memory to
perform the function specified on
the second line of the error
message.
Free up some of the printer’s memory
by adjusting the label format or printer
parameters. One way to free up
memory is to adjust the print width to
the actual width of the label instead of
leaving the print width set to the
default. See Set Print Width
on page 94.
Ensure that the device, such as FLASH
memory or PCMCIA card, is installed
and not write protected or full.
Ensure that the data is not directed to a
device that is not installed or is
unavailable.
Refer to the Maintenance Manual for
more information about the specified
function.
Table 12 • LCD Error Messages (Continued)
LCD Display/
Printer Condition
Possible Cause Recommended Solution

Zebra 110Xi4 Specifications

General

Maximum resolution	203 x 203 DPI
Core diameter	76 mm
Ribbon length	300 m
Media thickness	0.076 - 0.305 mm
Maximum media length	3810 mm
Maximum roll diameter	203 mm
Supported paper width	102 mm
Media thickness (imperial)	0.003 - 0.012 \
Maximum media length (imperial)	150 \
Supported paper width (imperial)	4 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	50 lbs
Dimensions (WxDxH)	261.9 x 517.5 x 393.7 mm
Flash memory	8 MB
Certification	-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory	16 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	XML, ZPL, ZPL II
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Power requirements	90 - 264 VAC, 48 - 62 Hz

Weight and Dimensions

Weight	22700 g
