45
Operations
Load Media in Tear-Off Mode
3/12/09 Xi4 User Guide P1009874-001
7. Push the media forward until it passes under the printhead assembly (1), under the
snap plate (
2), and then over the platen roller (3).
8. Align the media with the inner media guide (1). Slide in the outer media guide (2) until it
just touches the edge of the media.
