Operations
Load Media in Tear-Off Mode
46
P1009874-001 Xi4 User Guide 3/12/09
9. Tighten the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
10. Push down the printhead assembly (1), and then rotate the printhead-open lever (2)
clockwise until it locks into place.
1
12
