Operations
Load Media in Peel-Off Mode
50
P1009874-001 Xi4 User Guide 3/12/09
7. If your printer includes a media dancer assembly (1), thread the media under the media
dancer assembly roller. For all printers, thread the media under the media guide roller (
2)
and then the upper media sensor (
3).
8. Push the media forward until it passes under the printhead assembly (1), under the
snap plate (
2), and then over the platen roller (3).
Important • Make sure that you thread the media under these components. If you thread
the media over the them, the media obstructs the ribbon sensor and causes a false
RIBBON OUT error.
