51
Operations
Load Media in Peel-Off Mode
3/12/09 Xi4 User Guide P1009874-001
9. Extend approximately 36 in. (920 mm) of media out of the printer. Remove and discard
the labels from this exposed media.
10. Remove the hook from the rewind spindle.
11. If you are using a core, slide it onto the rewind spindle until it is flush against the guide
plate.
Note • A core is not required.
To Next Page
