61
Operations
Load Media in Rewind Mode
3/12/09 Xi4 User Guide P1009874-001
7. Insert media into the printer. See Prepare the Media for Loading on page 39 for
instructions.
8. Open the printhead assembly by rotating the printhead-open lever (1) counter-clockwise.
9. Loosen the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
10. Slide the outer media guide (1) all the way out.
