Operations
Load Ribbon
70
P1009874-001 Xi4 User Guide 3/12/09
6. Open the printhead assembly by rotating the printhead-open lever counter-clockwise.
7. Does your printer contain a ribbon dancer assembly? (See Figure 11 on page 68 for the
ribbon dancer location.)
If... Then...
No Thread the ribbon over the media dancer assembly (1) and under the
ribbon guide roller (
2).
2
1
