12 DS2278 Digital Scanner Quick Start Guide
Cradle
123Scan
123Scan is an easy-to-use, PC-based software tool that enables rapid and easy customized setup of a scanner via
a bar code or USB cable. For more information, visit: http://www.zebra.com/123Scan
.
Utility Functionality
•
Device configuration
•
Electronic programming (USB cable)
•
Programming bar code(s)
•
Data view - scan log (display scanned bar code data)
•
Access asset tracking information
•
Upgrade firmware and view release notes
•
Remote management (SMS package generation).
No power to scanner Off
Scanner dock in cradle Single green flash
Digital scanner is ready to scan Green
Bar code is successfully decoded Off momentarily
Transmission error Red
Charging with Micro USB Connection
Digital scanner is charging Green flash (fast continuous)
Digital scanner is fully charged Green (solid)
Initial connection Single green flash
Charge error Red (solid)
Table 3 Cradles LED Indications
Indication LED Indicator
Standard Use
Power Up Green (stays on)
Radio Indications
Bluetooth connection established Green (off, then on)
Battery Indications
Charging Amber blinking
Fully charged Green (solid)
Charging error Amber fast blinking
Table 2 Scanner LED Indications (Continued)
Indication LED Indicator
